DS-CL-456-MPL-R
Function：
1, Air circulation purification
2, Sterilization and disinfection
3, Main Lighting
4, Night light
| Sterilization Type | Removal Rate |
| SARS, Corona Virus | 99.99% |
| H1N1 | 99.99% |
| Candida albicans | 90.90% |
| Escherichia coli | 99.91% |
| Staphylococcus aureus | 99.90% |
| Pseudomonas aeruginosa | 99.99% |
| Formaldehyde | 99.99% |
| TVOC | 99.99% |
Removal Rate
| Sterilization Type | Killing Rate | Testing Organization |
| H1N1 | 99.99% | SGS group |
| Escherichia coli | 99.99% | Guangzhou Institute of Microbiology |
| Klebsiella pneumoniae | 99.99% | SGS group |
| Staphylococcus albus | 86.7% | SGS group |
| Air natural bacteria | 79.1% | SGS group |
Specification：
| Item | DS-CL-456-MPL-R |
| Total Power | 60W |
| Luminous Flux: | 3600lm |
| Dimension: | D456*116mm |
| Tinting Temperature | Yes |
| Dimmable | Yes |
| Purification Capacity | Max 150m³ / Hrs |
| Filter Level | H13 （Hepa 13） |
| UGR | <22 |
| Power Factor | >0.9 Flicker free |
| CRI | >80Ra |
| Frame Color | White |
| Input Voltage | AC200-240V |
| Frequency | 50/60Hz |
| Lifespan | 25,000Hrs |
| Packing | 1pc/ctn |
| Module | Rated Power | Output Power | Control Method |
| Main LED Lighting | 36W | 1.8-36W | Stepless color temperature and brightness dimming |
| Small Night Light | 8W | 0.5-8W | Warm light stepless dimming,gradually open and close |
| UVA Light | 2W | 6W | ON / OFF |
| Fan | 12W | 3-12W | Segmented Control 20% 40% 60% |
Features：
1. Air circulation purification, sterilization and disinfection, main lighting, small night light,
2. 360 degree all-round cleaning of indoor air.
3. Titanium oxide + Nano silver + filter + UVA light+ centrifugal fan, effectively remove viruses, bacteria, formaldehyde, benzene, PM2.5 and other harmful substances in the air.
4. Equipped with 2.4G remote controller, it is more convenient to adjust the color temperature, brightnes,wind speed, timing and other functions
5. Timing function 0.5h
6. Nine levels of brightness adjustment, 2700K~6500K, nine levels of color matching temperature, flicker free
7. Simple, fashionable and beautiful appearance, super suitable for home lighting
8. Small size D456*H116mm, reduce transportation costs
9. Ceiling surface mounting installation, convenient installation, does not occupy indoor space
| Function | Principle | Effect |
| Air purification | Titanium oxide + Nano silver + filter + UVA light | Effective filtration of particles: PM2.5，Formaldehyde, TOVC, Benzene, smoke, musty...
99.99% remove H1N1, Coronavirus, Staphylococcus, Enterobacteriaceae... |
| Main Lighting | High efficiency LED lamp | Remote control the brightness and color temperature |
| Small night light | Warm LED | Back light, soft light |
| Air circulation | Fan | Multi speed regulation, accelerating indoor air circulation
0% off mode 20% Breeze sleep mode 40% Moderate wind mode 60% Storm mode |
3 kinds of superefficient sterilization and air purification systems
1. Titanium Oxide + Nano Silver
2. Filter Screen + Titanium Oxide +Nano Silver + Centrifugal Fan
Filter screen: spray titanium oxide and nano silver on the filter screen
Effectively filter aerosol and other particles (formaldehyde, PM2.5, hand smoke, peculiar smell and moldy smell);
Kill H1NI1 influenza virus, COVID-19, Staphylococcus, Escherichia coli and other harmful microorganisms;
Centrifugal fan can effectively promote air flow
3. UVA light + Titanium Oxide +Centrifugal Fan
when the main lighting is turned off, the combination of purple light + titanium oxide can achieve the air purification effect, through the principle of photocatalyst.
24Hrs air purification
Centrifugal Fan 3-gear speed Regulation
Nighttime: 20% Breeze sleep mode
Super quiet, fresh air, keep a good sleep
Daytime: 40% Moderate wind mode
Effectively improve the effect of air purification
Leaving time: 60% Storm mode
Circulating and purifying indoor air at high speed
