Feature
2-way rotatable
Ultra low glare UGR<17, more eye protection
Up to CRI 97Ra, highly restore original color
Kinds of beam angles are available
Up to 130lm/w lighting efficiency, more energy saving
Simple and fashionable appearance, meet the aesthetic requirements
8W 68mm cut-out, suitable for German market
Multiple dimming modes can be selected
Long lifespan, 5 years warranty
Multiple brands LED driver can be selected, no flicker
Parameters
| Input Voltage | 200-240V |
| Color Temperature | 2700K, 3000K, 4000K, 5000K, 6000K optional |
| Lighting Efficiency | Up to 130 LM/W |
| Waterproof Level | IP44 |
| Anti-Glare | UGR<17 / UGR <21 |
| CRI | 80Ra / 90Ra / 97Ra |
| Power Factor | >0.9 |
| Lifetime | 50,000H |
| Dimmable | N / 0-10V / Triac Dim / Dali / 2.4G / Dim to Warm 1800-3000K / 2700-5700K CCT tunable Optional |
| Installation | Recessed |
Specification
| Item | Power | Luminous Flux (lm) | Dimension (mm) | Cut-out (mm) | Beam Angle |
| DS-CL-8W-5 | 8W | 750-850 | D77*H60 | D65-70 | 24°; 40°; 60°; |
| DS-CL-14W-5 | 14W | 1400-1500 | D120*H80 | D95-108 | 15°; 24°; 30°; 40°; 60°; |
| DS-CL-20W-5 | 20W | 2200-2400 | D145*H105 | D118-132 | 15°; 24°; 30°; 40°; 60°; |
| DS-CL-30W-5 | 30W | 3500-3800 | D170*H120 | D145-155 | 15°; 24°; 30°; 40°; 60°; |
| DS-CL-40W-5 | 40W | 4500-4800 | D200*H130 | D165-180 | 15°; 24°; 30°; 40°; 60°; |
| DS-CL-50W-5 | 50W | 5700-6000 | D250*H126 | D205-230 | 15°; 24°; 30°; 45°; 65°; |
| DS-CL-70W-5 | 70W | 7000-7500 | D250*H140 | D205-230 | 15°; 24°; 30°; 45°; 65°; |
